Automatic woven fabric spreading machine (For woven fabric )

Automatic woven fabric spreading machine (For woven fabric )

Item No.: BW-1600BSW/BW-1900BSW

Automatic fabric spreading machine special design for woven fabric

INQUIRY

Description Specification Operation video

This machine is equip with PLC programmable computer control .Adopt advance touch screen operate .It is convenient to set the functions such as the fabric spreading type .length ,number of layers and speed .Can reduce the accident caused by the length setting and human negligence

Machine feathers :
A, LCD touch device: easy to set the length, mode, quantity, speed and paragraph.
B. Cloth device: It can adjust the distribution of the fabric according to the width and tension of the fabric, so that the fabric does not wrinkle.
C. Cuttering device: The cutting knife and the main machine can be easily disassembled and assembled. When the fabric is cut, the walking distance and cutting speed of the cutting knife can be set according to the cloth width. Folding device: can be used for one-way and round-trip.
D. Automatic cloth pre-loosening device: firstly release the cloth and release the spreading tension and maintain the consistency of the spreading quality.
E, electric eye automatic edge device: correctly detect the edge of the fabric, can automatically achieve the opposite edge during the spreading operation.
F, cloth tail sensor device: When the cloth is finished, the control host automatically stops the movement, and automatically completes the zero return of the origin and resets the fixed point.
Automatic ascending device: Set the amount of rise according to the thickness of the fabric to match the height of the spread. Emergency stop device: There are steel cables for shutdown on both sides of the cutting machine, which can pull the steel rope at any position at any time for emergency stop.

Model	BW-1600BSW	BW-1900BSW
Spreading width	1600MM	1900MM
Cloth pulling height	200MM	200MM
Maximum speed	80M/MIN	80M/MIN
Maximum diameter of cloth roll	400MM	400mm
Weight of cloth roll	50kg	50kg
Cutting table width	1830mm	2130mm
Cutting table height	700±30mm	700±30mm
Voltage	220V/50-60hz	220V/50-60HZ
Power	2.0KW	2.0KW
DIMENSION	15002170750	15002470750
