Automatic fabric spreading &cutting machine (For woven fabric)

Item No.: BW-1600BSL/BW-1900BSL

BW series automatic spread machine started to cloth spread ,typesetting ,cutting in one special equipment to system integration

INQUIRY

Description Specification

Suitable for cloth ,leather ,paper ,fabric or other material .Plate making layout CAD date .Spread the cloth .Cut out one machine to complete .PLC control module .Multi -point touch screen operation widow in Chinese and english .Can quick set spread cloth layer,length,cutting speed set operations.Such us using bucket roller of fabric design .can support up to 45cm in diameter .The wireless remote control and infrared sensors to ensure the running safety .

Widely use for soft furniture,interior and leather .

Model	BW-1600BSL	BW-1900BSL
Max spread width	1600MM	1900MM
Max spread height	200MM
Max spread speed	80M/MIN
Max cutting height	3-10MM(Base on different material )
Max cutting speed	8m/min
Cutting head	Oscillating knife
Cutting power	9kw
Working temperature	0-45℃
Working humidity	10%-90% (no condensate )
Weight	450kg
